JTAG-Booster for Analog Devices ADSP-21xxx
Sample File JTAG161.INI:
// Description file for Analog Devices ADSP-21161
Target: Generic Target with ADSP-21161
// All chip select signals are set to output and inactive.
// All signals should be defined. Undefined signals are set to their defaults
// Pin Names are defined in upper case
// Low Active Signal are signed with a trailing #
// The following pins are complete bidirectional pins
// The direction of each pin can be set independent of the other pins
// Each pin can be used as an input
EBOOT Inp // EPROM Boot Select, EBOOT=1 -> Boot from EPROM
LBOOT Inp // Link Boot, should be low for EBOOT=1
WR# Out,Hi // Memory Write Strobe = WE# of Flash-EPROM
RD# Out,Hi // Memory Read Strobe = OE# of Flash-EPROM
BMS# Out,Hi // Boot Memory Select = CS# of Flash-EPROM
MS0# Out,Hi // Memory Select Lines
MS1# Out,Hi //
MS2# Out,Hi //
MS3# Out,Hi //
BMSTR Out,Hi // Bus Master Output
EMU# Inp // Emulation Status Output
RESET# Inp // Processor Reset Input
FLAG11
FLAG10
FLAG9
FLAG8
FLAG7
FLAG6
FLAG5
FLAG4
FLAG3
FLAG2
FLAG1
FLAG0
IRQ0#
IRQ1#
IRQ2#
ID0
ID1
32
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
// Flag Pins
//
//
//
//
//
//
//
//
//
//
//
// Interrupt Request Lines
//
//
// Multiprocessing ID
//
JTAG_ADSP-21xxxa.doc
